MODEL NAME

SHX12000Di

TYPE

R

LD

FREQUENCY (Hz)

50

60

ALTERNATOR

Type

Permanent Magnet, Multi-PoleAlternator

Phase

Single

Voltage RegulationSystem

Inverter

Waveform

Pure Sine Wave

Output

Maximum

11.0 kVA

Rated

10.2 kVA

Voltage (V)

220

120/240

Current (A)

46.4

2 x 46.4 - 46.4

Rated Power Factor (cos)

1.0

ENGINE

Maker

YANMAR

Model Name

3TNM68 - ASG

Displacement (L)

0.784

Rated Output (kW / rpm)

13.8 / 3600

Engine Speed (rpm)

2300 - 3400, VARIABLE

Starting System

Electric Starter

Fuel

Diesel Fuel(BS2869A1 or equivalent)

Cooling Type

Radiator

Battery (5HR)

12 - 36(46B24L)

Others

L x W x H (mm)

1184 x 670 x 770

Dty Weight (kg)

278

Fuel Tank Capacity (L)

40.7

Sound Level[dB(A) / 7m]FuelConsumption(L / h)

25% Load

64.0

75% Load

66.0

100% Load

68.0

FuelConsumption(L / h)

25% Load

1.6

50% Load

2.3

75% Load

3.2

100% Load

4.3

Volt Meter

YES

Hour Meter

YES (LED Display)

Warning Lights

Output

Plug Socket x 3

Plug Socket x 5

ATS Terminal

YES
